Visa OCR API

The following document highlights the details of the Visa OCR API.

API Description

Objective

The Visa OCR API extracts data from visa documents using Optical Character Recognition (OCR) technology and returns the information in JSON format.

Visa OCR API

This API supports three major visa document variants: printed, digital, and stamped. The API is country-agnostic and can process visa documents from most countries, provided the documents contain relevant keywords that enable detection.

Input	Output
The image of a visa document	OCR results containing visa number, issue date, validity date, confidence scores, and review flags

classifier logic

The Visa classifier, which is the document identification mechanism used by the Visa OCR API, is primarily keyword-based and uses fuzzy matching to identify specific keywords such as "VISA", "Migration", and other relevant terms to detect and validate visa documents.

API URL

https://ind-engine.thomas.hyperverge.co/v1/visaOCR

API Endpoint

visaOCR

Overview

The Visa OCR API is RESTful and uses standard HTTP verbs and status codes. The responses are in JSON format, and you should upload all images and files as form-data through a POST request.

Method - `POST`

Authentication

You need a unique pair of application ID ( appId ) and application key ( appKey ) from HyperVerge to verify your identity for accessing the Visa OCR API.

Headers

Header	Mandatory / Optional	Description	Input Format
content-type	Mandatory	This parameter defines the media type for the request payload	multipart/form-data
appId	Mandatory	The application identifier shared by HyperVerge. You can find the details in the dashboard's credentials tab	This should be a unique value
appKey	Mandatory	The application key shared by HyperVerge. You can find the details in the dashboard's credentials tab	This should be a unique value

Inputs

The following table provides the details of the parameters required for the Visa OCR API's request body:

Parameter	Mandatory / Optional	Type	Description	Input Format	Default Value
`image`	Mandatory	file	The visa document image file to be processed	Image file (JPEG, JPG, or PNG) with a maximum size of 6MB, or a PDF file	Not Applicable

Caution

When multiple images are included in a single API request, only one image is processed. Ensure that each API call contains a single image.
For PDF files with multiple pages, only the first page is processed for OCR extraction.

Request

The following code snippet demonstrates a standard curl request for the Visa OCR API:

curl --location --request POST 'https://ind-engine.thomas.hyperverge.co/v1/visaOCR' \
--header 'appid: <Enter_the_appId-Shared-by-HyperVerge>' \
--header 'appkey: <Enter_the_appKey-shared-by-HyperVerge>' \
--form 'image=@"<Enter_the_image_file_path>"'

Document Sample

The following is a sample Visa document:

Supported Visa Variants

The API supports OCR extraction from three major visa document variants:

Printed Visas: Traditional printed visa documents with standard formatting

Digital Visas: Electronically generated visa documents

Stamped Visas: Physical visa stamps on passport pages

Success Response

The following code snippet demonstrates a success response from the Visa OCR API:

{
    "status": "success",
    "statusCode": 200,
    "metaData": {
        "requestId": "<Request_ID>"
    },
    "result": [
        {
            "details": {
                "visa_number": {
                    "value": "<Visa_Number>",
                    "conf": <Confidence_Score>,
                    "to-be-reviewed": "<Review_Flag>"
                },
                "issue_date": {
                    "value": "<Issue_Date>",
                    "conf": <Confidence_Score>,
                    "to-be-reviewed": "<Review_Flag>"
                },
                "validity": {
                    "value": "<Validity_Date>",
                    "conf": <Confidence_Score>,
                    "to-be-reviewed": "<Review_Flag>"
                }
            },
            "type": "visa"
        }
    ]
}

Success Response Details

The following table outlines the details of the success response from the Visa OCR API:

Parameter	Type	Description
`status`	string	The status of the API request indicating success or failure
`statusCode`	integer	The HTTP status code for the response
`metaData`	object	The JSON object containing request identifiers
`requestId`	string	The unique identifier for tracking the request
`result`	array	The array containing the extracted visa information
`details`	object	The JSON object containing the extracted visa fields
`visa_number`	object	The object containing the unique visa identification number extracted from the document
`visa_number.value`	string	The extracted visa number value from the visa document
`visa_number.conf`	float	The confidence score for the visa number extraction, ranging from 0 to 1, where 0 indicates low confidence and 1 indicates high confidence
`visa_number.to-be-reviewed`	string	The flag indicating if manual review is required for the visa number, set to "yes" when confidence is low or when validity period exceeds 10 years, otherwise "no"
`issue_date`	object	The object containing the date when the visa was issued, extracted from the document
`issue_date.value`	string	The extracted issue date value in DD/MM/YYYY format
`issue_date.conf`	float	The confidence score for the issue date extraction, ranging from 0 to 1, where 0 indicates low confidence and 1 indicates high confidence
`issue_date.to-be-reviewed`	string	The flag indicating if manual review is required for the issue date, set to "yes" when confidence is low or when validity period exceeds 10 years, otherwise "no"
`validity`	object	The object containing the date when the visa expires, extracted from the document
`validity.value`	string	The extracted validity date value in DD/MM/YYYY format
`validity.conf`	float	The confidence score for the validity date extraction, ranging from 0 to 1, where 0 indicates low confidence and 1 indicates high confidence
`validity.to-be-reviewed`	string	The flag indicating if manual review is required for the validity date, set to "yes" when confidence is low or when validity period exceeds 10 years, otherwise "no"
`type`	string	The document type identifier, which always returns "visa" for visa documents

Failure Response

The following code snippet demonstrates a failure response from the Visa OCR API:

{
    "status": "failure",
    "statusCode": 400,
    "message": "Input Validation Error: requires property \"image\""
}

Error Responses

The following are some error responses from the Visa OCR API:

Missing Image Input
Image Size Exceeds Limit
Document Not Detected
Internal Server Error

{
    "message": "Input Validation Error: requires property \"image\"",
    "statusCode": 400,
    "status": "failure"
}

{
    "statusCode": 400,
    "status": "failure",
    "error": "Image size cannot be greater than 6MB"
}

{
    "status": "failure",
    "statusCode": 422,
    "error": "Document Not Detected",
    "metaData": {
        "requestId": "<Request_ID>"
    }
}

{
    "status": "failure",
    "error": "internal server error",
    "statusCode": 500
}

Error Response Details

A failure or error response contains a failure status with a relevant status code and error message.
The following table lists all error responses:

Status Code	Error Message	Error Description	Error Resolution
400	Input Validation Error: requires property "image"	The request is missing the required `image` parameter	Ensure the request includes the `image` parameter with a valid image file
400	Image size cannot be greater than 6MB	The uploaded image file exceeds the maximum allowed size of 6MB	Compress or resize the image to ensure it is under 6MB before uploading
422	Document Not Detected	The request does not contain a valid visa document, or a non-visa document was uploaded	Ensure the uploaded image contains a valid visa document with standard visa-related keywords for successful detection
500	internal server error	An unexpected server error occurred during processing	Check the request headers or contact the HyperVerge team for resolution
